Ball Valve

FCA
RISING STEM BALL VALVE

FCA Top Entry Rising Stem

FCA BR Model

FCA Rising stem ball are specially engineered for heavy duty applications outstanding at high pressure working conditions, up to ASME Class 2500# and sizes up to 24”.

Features
  • Friction-Free
  • Self cleaning operation
  • Zero leakage
  • Single seat
FCA Rating
  • FCA Rising Stem Ball Valve Class 150
  • FCA Rising Stem Ball Valve Class 300
  • FCA Rising Stem Ball Valve Class 600
  • FCA Rising Stem Ball Valve Class 900
  • FCA Rising Stem Ball Valve Class 1500
  • FCA Rising Stem Ball Valve Class 2500
Design StandardAPI / ASME
SizesDN50/2'' to DN600/24''
Sectors- Oil and Gas - Petrochemical Plants
MaterialBody : ASTM A216 WCB / A351 CF8M / A995 4A Ball     : ASTM A105+ENP / A182 F316 / A182 F304 / A182 F51
SeatDEVLON, MOLON, Metal/Metal, NYLON, PEEK, PTFE, RPTFE, Viton
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsBlock and bypass, Dryer switching, Meter isolation, Molecular Sieve dehydratation switches, Product segregation, Steam and Gas
Accessories & OptionsDrain & Vent valves, Emergency System, Filters, Full or Reduced Bore, Inyectors, Junction box, Limit Switches, Locking devices, Proximity switches, Solenoid valve, Stem extension

FCA Floating and Trunnion Mounted Ball Valve

FCA Floating Mounted Design

FCA Ball are specially engineered for heavy duty applications outstanding at high pressure working conditions, up to ASME Class 2500# and sizes up to 36”.

Features
  • Soft or metal seated
  • Blowout proof stem
Accesories & Option
  • Antistatic devices
  • Self-relieving seating
FCA Rating
  • FCA Split Body Ball Valve Class 150
  • FCA Split Body Ball Valve Class 300
  • FCA Split Body Ball Valve Class 600
Design StandardAPI / ASME
SizesDN50/2'' to DN900/36''
Sectors- Mineral - Oil and Gas - Petrochemical Plants - Power - Steel Industry - Water
MaterialBody : ASTM A216 WCB / A351 CF8M / A995 4A Ball     : ASTM A105+ENP / A182 F316 / A182 F304 / A182 F51
SeatDEVLON, MOLON, Metal/Metal, NYLON, PEEK, PTFE, RPTFE, Viton
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsCorrosive fluids, Natual Gas Pipelines, Oil Pipelines, Refineries, Water pump stations
Accessories & OptionsAnti-static device, Cavity Relief, Drain & Vent valves, Emergency System, Filters, Full or Reduced Bore, Inyectors, Junction box, Limit Switches, Locking devices, Proximity switches, Solenoid valve, Stem extension

FCA
FLOATING SPLIT BODY
BALL

FCA Floating and Trunnion Mounted Ball Valve

FCA Floating Mounted Design

FCA Ball are specially engineered for heavy duty applications outstanding at high pressure working conditions, up to ASME Class 2500# and sizes up to 36”.

Features
  • Soft or metal seated
  • Blowout proof stem
Accesories & Option
  • Antistatic devices
  • Self-relieving seating
FCA Rating
  • FCA Split Body Ball Valve Class 150
  • FCA Split Body Ball Valve Class 300
  • FCA Split Body Ball Valve Class 600
Design StandardAPI / ASME
SizesDN50/2'' to DN900/36''
Sectors- Mineral - Oil and Gas - Petrochemical Plants - Power - Steel Industry - Water
MaterialBody : ASTM A216 WCB / A351 CF8M / A995 4A Ball     : ASTM A105+ENP / A182 F316 / A182 F304 / A182 F51
SeatDEVLON, MOLON, Metal/Metal, NYLON, PEEK, PTFE, RPTFE, Viton
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsCorrosive fluids, Natual Gas Pipelines, Oil Pipelines, Refineries, Water pump stations
Accessories & OptionsAnti-static device, Cavity Relief, Drain & Vent valves, Emergency System, Filters, Full or Reduced Bore, Inyectors, Junction box, Limit Switches, Locking devices, Proximity switches, Solenoid valve, Stem extension

FCA
FLOATING SPLIT BODY
BALL

FCA
TRUNNION TOP ENTRY BALL

FCA Ball Valve

Top Entry FCA BS and BT Model Ball Valve

BS and BT model FCA Ball valve solutions ensure a perfect performance at primary and secondary sealing due to an accurate design concept at any size.

Features
  • Anti-static device
  • Blowout proof stem
  • Fire safe design
FCA Rating
  • FCA Top Entry Ball Valve Class 150
  • FCA Top Entry Ball Valve Class 300
  • FCA Top Entry Ball Valve Class 600
  • FCA Top Entry Ball Valve Class 900
  • FCA Top Entry Ball Valve Class 1500
  • FCA Top Entry Ball Valve Class 2500
Design StandardAPI / ASME
SizesDN50/2'' to DN900/36''
Sectors- Oil and Gas - Petrochemical Plants - Water
MaterialBody : ASTM A216 WCB / A351 CF8M / A995 4A Ball     : ASTM A105+ENP / A182 F316 / A182 F304 / A182 F51
SeatDEVLON, MOLON, Metal/Metal, NYLON, PEEK, PTFE, RPTFE, Viton
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsCorrosive fluids, Natual Gas Pipelines, Oil Pipelines, Refineries
Accessories & OptionsAnti-static device, Cavity Relief, Drain & Vent valves, Emergency System, Filters, Full or Reduced Bore, Inyectors, Junction box, Limit Switches, Locking devices, Proximity switches, Solenoid valve, Stem extension

FCA Butterfly Valve Double and Triple Eccentric

The MB Model FCA Bieccentric Butterfly Valve

The MB model FCA butterfly is mainly used in distribution networks and pumping stations. Is provided with a circular flanged body and a butterfly or disc as clogging element.

Features
  • Minimal wear
  • Low pressure loss
  • Double eccentric design
  • Extecded stem availability
  • Low operation torques
FCA Rating
  • FCA Butterfly Valve Class 150
  • FCA Butterfly Valve Class 300
  • FCA Butterfly Valve Class 600
Design StandardAWWA / DIN
PressurePN6 / PN10 / PN16 / PN25 / PN40
SizesDN400/16'' to DN2500/100''
Sectors- Hydro Power Plants and Dams - Power
MaterialsBody : Carbon Steel / Stainless Steel Disc    : Carbon Steel / Stainless Steel
SeatEPDM, SS
Operation typeHydraulic Actuator
ApplicationsEmergency functions for Hydraulic power stations, Turbines
Accessories & OptionsBy-pass, Dismantling Joints, Emergency System, Emergency closing devices, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Special Supports, Stem extension

FCA
BIECCENTRIC BUTTERFLY

FCA Butterfly Valve Double and Triple Eccentric

The MB Model FCA Bieccentric Butterfly Valve

The MB model FCA butterfly is mainly used in distribution networks and pumping stations. Is provided with a circular flanged body and a butterfly or disc as clogging element.

Features
  • Minimal wear
  • Low pressure loss
  • Double eccentric design
  • Extecded stem availability
  • Low operation torques
FCA Rating
  • FCA Butterfly Valve Class 150
  • FCA Butterfly Valve Class 300
  • FCA Butterfly Valve Class 600
Design StandardAWWA / DIN
PressurePN6 / PN10 / PN16 / PN25 / PN40
SizesDN400/16'' to DN2500/100''
Sectors- Hydro Power Plants and Dams - Power
MaterialsBody : Carbon Steel / Stainless Steel Disc    : Carbon Steel / Stainless Steel
SeatEPDM, SS
Operation typeHydraulic Actuator
ApplicationsEmergency functions for Hydraulic power stations, Turbines
Accessories & OptionsBy-pass, Dismantling Joints, Emergency System, Emergency closing devices, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Special Supports, Stem extension

FCA
BIECCENTRIC BUTTERFLY

FCA
BIECCENTRIC COUNTERWEIGHT

FCA Bieccentric Butterfly Valve With Counterweight

The MBC Model FCA Bieccentric Butterfly Valve

The MBC model FCA butterfly is mainly used in strained lines in hydraulic power stations or as a charge or discharge valve and for security purposes in turbines as a shut-off element.

Features
  • API 609 compliance
  • FCA bieccentric soft or metal seated configurations
  • Double flanged, wafer or Lug type and buttwelded configurations.
FCA Rating
  • FCA Butterfly Valve Class 150
  • FCA Butterfly Valve Class 300
  • FCA Butterfly Valve Class 600
Design StandardAWWA / DIN
PressurePN6 / PN10 / PN16 / PN25 / PN40
SizesDN400/16'' to DN2500/100''
Sectors- Hydro Power Plants and Dams - Power
MaterialsBody : Carbon Steel / Stainless Steel Disc    : Carbon Steel / Stainless Steel
SeatEPDM, SS
Operation typeHydraulic Actuator
ApplicationsEmergency functions for Hydraulic power stations, Turbines
Accessories & OptionsBy-pass, Counter-weight, Dismantling Joints, Emergency System, Emergency closing devices, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Special Supports, Stem extension

FCA Eccentric Butterfly Valve

The MD Model Double Eccentric Butterfly Valve

The MD double eccentric butterfly model consists of a body with a sealing gasket (fixed with a steel ring) that allows a tight sealing of the disc. This design prevents fluid contact with the valve body to avoid corrosion.

Features
  • Eccentric butterfly anti Blow-out proof one-piece shaft design
  • FCA butterfly wide range of body, bonnet and trim materials
  • Double eccentric bi-directional flow capability upon request
  • Extended stem availability
FCA Rating
  • FCA Butterfly Valve Class 150
  • FCA Butterfly Valve Class 300
  • FCA Butterfly Valve Class 600
Design StandardAPI / ASME / GB
SizesDN50/2'' to DN1200/48''
Sectors- Minerals - Oil and Gas - Petrochemical Plants - Water
MaterialBody        : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A... Disc          : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A... Packing : Graphite / PTFE
SeatNBR, PTFE+SS, SS+Graphite
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsAbrasive media, Bypass systems, Drain systems, Equipment isolation, Liquid media (Water, Oil…) and Gases, On/off service
Accessories & OptionsEmergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA
DOUBLE ECCENTRIC BUTTERFLY

FCA Eccentric Butterfly Valve

The MD Model Double Eccentric Butterfly Valve

The MD double eccentric butterfly model consists of a body with a sealing gasket (fixed with a steel ring) that allows a tight sealing of the disc. This design prevents fluid contact with the valve body to avoid corrosion.

Features
  • Eccentric butterfly anti Blow-out proof one-piece shaft design
  • FCA butterfly wide range of body, bonnet and trim materials
  • Double eccentric bi-directional flow capability upon request
  • Extended stem availability
FCA Rating
  • FCA Butterfly Valve Class 150
  • FCA Butterfly Valve Class 300
  • FCA Butterfly Valve Class 600
Design StandardAPI / ASME / GB
SizesDN50/2'' to DN1200/48''
Sectors- Minerals - Oil and Gas - Petrochemical Plants - Water
MaterialBody        : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A... Disc          : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A... Packing : Graphite / PTFE
SeatNBR, PTFE+SS, SS+Graphite
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsAbrasive media, Bypass systems, Drain systems, Equipment isolation, Liquid media (Water, Oil…) and Gases, On/off service
Accessories & OptionsEmergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA
DOUBLE ECCENTRIC BUTTERFLY

FCA
STANDARD BUTTERFLY

FCA Standard Butterfly Valve

The MS Type Standard Butterfly Valve Model

The MS type standard butterfly model consists of a body with a sealing gasket (fixed with a steel ring) that allows a tight sealing of the disc and this design prevents fluid contact.

Features
  • Top flange standard
  • Reduces valve torque
Accesories & Option
  • Proximity switches
  • Stem extension
FCA Rating
  • FCA Standard Butterfly Valve Class 150
  • FCA Standard Butterfly Valve Class 300
  • FCA Standard Butterfly Valve Class 600
Design StandardAPI / ASME / GB / MSS
PressureUp to 16bar
SizesDN50/2'' to DN1200/48''
Sectors- Minerals - Oil and Gas - Petrochemical Plants - Power - Steel Industry - Water
MaterialsBody        : ASTM A216 WCB / A351 CF8 Disc          : ASTM A216 WCB / A351 CF8 Stem        : AISI 316 Packing :Graphite
SeatEPDM, NBR, Neoprene, PTFE, Viton
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsAbrasive media, Bypass systems, Drain systems, Equipment isolation, Liquid media (Water, Oil…) and Gases, On/off service
Accessories & OptionsEmergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA Centered Axis

The MT Model Triple Eccentric Butterfly Valve

Centered axis or eccentric butterfly do not present the correct performance when used for severe applications such as high temperatures or at high opening and closing frequencies.

Sectors
  • Oil & gas
  • Mineral processing
  • Petrochemical plants
Applications
  • Water pipelines
  • Equipment isolation
  • Drain systems
FCA Rating
  • FCA Butterfly Valve Class 150
  • FCA Butterfly Valve Class 300
  • FCA Butterfly Valve Class 600
Design StandardAPI / ASME / GB
PressurePN6 / PN10 / PN16 / PN25 / PN63
SizesDN50/2'' to DN1200/48''
Sectors- Mineral Processing - Oil and Gas - Petrochemical Plants - Water
MaterialsBody        : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A... Disc          : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A... Packing : Graphite / PTFE
SeatNBR, PTFE+SS, SS+Graphite
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsAbrasive media, Bypass systems, Drain systems, Equipment isolation, Liquid media (Water, Oil…) and Gases, On/off service
Accessories & OptionsEmergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA
TRIPLE ECCENTRIC BUTTERFLY

FCA Centered Axis

The MT Model Triple Eccentric Butterfly Valve

Centered axis or eccentric butterfly do not present the correct performance when used for severe applications such as high temperatures or at high opening and closing frequencies.

Sectors
  • Oil & gas
  • Mineral processing
  • Petrochemical plants
Applications
  • Water pipelines
  • Equipment isolation
  • Drain systems
FCA Rating
  • FCA Butterfly Valve Class 150
  • FCA Butterfly Valve Class 300
  • FCA Butterfly Valve Class 600
Design StandardAPI / ASME / GB
PressurePN6 / PN10 / PN16 / PN25 / PN63
SizesDN50/2'' to DN1200/48''
Sectors- Mineral Processing - Oil and Gas - Petrochemical Plants - Water
MaterialsBody        : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A... Disc          : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A... Packing : Graphite / PTFE
SeatNBR, PTFE+SS, SS+Graphite
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsAbrasive media, Bypass systems, Drain systems, Equipment isolation, Liquid media (Water, Oil…) and Gases, On/off service
Accessories & OptionsEmergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA
TRIPLE ECCENTRIC BUTTERFLY

FCA
ECCENTRIC PLUG CONTROL VALVE

FCA Control

Eccentric Plug Control

FCA TE model is a rotatory control with an eccentric plug inside. The valve plug addopts an spherical surface that when turning the plug shaft from closed to open position, the eccentric plug design lifts off the seat smoothly, so open and close torque values are minimized.

Features

  • Balance cylinder
  • Exceed valve performance requirements

Accesories & Option

  • Anti-cavitation trim
  • Wide range of actuation types
Design StandardAPI / ASME
SizesDN50/2'' to DN600/24''
Sectors- Minerals - Oil and Gas - Pterochemical Plants - Water
MaterialBody        : A216-WCB / A351-CF8 / CF8M / A890 Gr4A Plug          : A216-WCB / A351-CF8 / CF8M / A890 Gr4A (+Stellite) Stem        : Stainless Steel / Inconel Packing : PTFE / Graphite
SeatSS, SS+Stellite
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsGas, Liquid media, Slurry, Steam
Accessories & OptionsBy-pass, Emergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA Control

Globe Control

The TG and TGM control model from FCA is a robust and heavy-section globe valve with a plug designed to accurately control the flow. It is a high performance valve with high flow capacity and a tight shut-off.

Features

  • Balance cylinder
  • Includes the seat ring
  • Trouble-free service



Accesories & Option

  • Noise reduction trim
  • FTO and FTC configurations
Design StandardAPI / ASME
SizesDN50/2'' to DN600/24''
Sectors- Minerals - Oil and Gas - Petrochemical Plants - Water
MaterialBody        : A216-WCB / A351-CF8 / CF8M / A890 Gr4A Bonnet   : A216-WCB / A351-CF8 / CF8M / A890 Gr4A Stem        : Stainless Steel / Inconel Packing : V-PTFE / Graphite
SeatSS, SS+Stellite
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsLiquid media, Modulating and on/off services, Slurry
Accessories & OptionsBy-pass, Emergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA
CONTROL VALVE

FCA Control

Globe Control

The TG and TGM control model from FCA is a robust and heavy-section globe valve with a plug designed to accurately control the flow. It is a high performance valve with high flow capacity and a tight shut-off.

Features

  • Balance cylinder
  • Includes the seat ring
  • Trouble-free service



Accesories & Option

  • Noise reduction trim
  • FTO and FTC configurations
Design StandardAPI / ASME
SizesDN50/2'' to DN600/24''
Sectors- Minerals - Oil and Gas - Petrochemical Plants - Water
MaterialBody        : A216-WCB / A351-CF8 / CF8M / A890 Gr4A Bonnet   : A216-WCB / A351-CF8 / CF8M / A890 Gr4A Stem        : Stainless Steel / Inconel Packing : V-PTFE / Graphite
SeatSS, SS+Stellite
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsLiquid media, Modulating and on/off services, Slurry
Accessories & OptionsBy-pass, Emergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA
CONTROL VALVE

FCA
CONTROL VALVE

FCA Control

Multi Stage Control Globe

The TG and TGM control model from FCA is a robust and heavy-section globe valve with a plug designed to accurately control the flow. It is a high performance valve with high flow capacity and a tight shut-off.

Features

  • Built for long-term
  • Trouble-free service
  • Different fluid parameters

Accesories & Option

  • Noise reduction trim
  • Standard or extended bonnet design
Design StandardAPI / ASME
SizesDN50/2'' to DN600/24''
Sectors- Minerals - Oil and Gas - Petrochemical Plants - Water
MaterialBody        : A216-WCB / A351-CF8 / CF8M / A890 Gr4A Bonnet   : A216-WCB / A351-CF8 / CF8M / A890 Gr4A Stem        : Stainless Steel / Inconel Packing : V-PTFE / Graphite
SeatSS, SS+Stellite
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsAnti-Cavitation, Continous working services, High pressure drops, Modulating services, Noise attenuation, Severe working applications
Accessories & OptionsBy-pass, Emergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA Standard Knife Gate Valve

The GB Model FCA Bonneted Knife Gate Valve

The GB model FCA knife gate is a welding fabricated valve. Its bonneted design structure provides full tightness to the atmosphere.

Features
  • Reduced turbulence
  • Reinforced seat ring
  • V or Pentagonal port availability
Accesories & Option
  • Deflector cone
  • Reinforced socket
  • Injection holes
FCA Rating
  • FCA Knife Gate Valve Class 150
  • FCA Knife Gate Valve Class 300
Design StandardANSI / DIN
PressureUp to PN40 (depending on size)
Sectors- Hydro Power - Oil and Gas - Power - Pulp and Paper - Water
MaterialBody        : Carbon Steel / AISI304 / AISI316 Bonnet   :Carbon Steel / AISI304 / AISI316 Knife        : AISI304 / AISI316 Packing : Synth+PTFE, Graphite, o-ring
SeatEPDM, Metal/Metal, PTFE, Silicone, Viton
Operation typeBevel Gear, Electric Actuator, Handwheel, Hydraulic Actuator, Lever, Pneumatic
ApplicationsChemical Plants, Mining, high working pressure applications
Accessories & OptionsBonnet, Deflector cone, Emergency System, Emergency closing devices, Filters, Injection holes, Junction box, Proximity switches, Reinforced socket, Scraper, Solenoid valves, Stem extension, V or pentagonal port

FCA
BONNETED KNIFE GATE VALVE

FCA Standard Knife Gate Valve

The GB Model FCA Bonneted Knife Gate Valve

The GB model FCA knife gate is a welding fabricated valve. Its bonneted design structure provides full tightness to the atmosphere.

Features
  • Reduced turbulence
  • Reinforced seat ring
  • V or Pentagonal port availability
Accesories & Option
  • Deflector cone
  • Reinforced socket
  • Injection holes
FCA Rating
  • FCA Knife Gate Valve Class 150
  • FCA Knife Gate Valve Class 300
Design StandardANSI / DIN
PressureUp to PN40 (depending on size)
Sectors- Hydro Power - Oil and Gas - Power - Pulp and Paper - Water
MaterialBody        : Carbon Steel / AISI304 / AISI316 Bonnet   :Carbon Steel / AISI304 / AISI316 Knife        : AISI304 / AISI316 Packing : Synth+PTFE, Graphite, o-ring
SeatEPDM, Metal/Metal, PTFE, Silicone, Viton
Operation typeBevel Gear, Electric Actuator, Handwheel, Hydraulic Actuator, Lever, Pneumatic
ApplicationsChemical Plants, Mining, high working pressure applications
Accessories & OptionsBonnet, Deflector cone, Emergency System, Emergency closing devices, Filters, Injection holes, Junction box, Proximity switches, Reinforced socket, Scraper, Solenoid valves, Stem extension, V or pentagonal port

FCA
BONNETED KNIFE GATE VALVE

FCA
SQUARE KNIFE GATE VALVE

FCA Knife Gate Valve

The GC Model FCA Square Knife Gate Valve

GC model FCA knife gate are designed for lines with square and rectangular shapes. These valve are mainly used for discharging bins, tanks and under hoppers for the storage.

Features
  • Full port opening
  • Low pressure drop
  • Reduced turbulance
Accesories & Option
  • Deflector cone
  • Proximity switches
FCA Rating
  • FCA Square Knife Gate Valve Class 150
  • FCA Square Knife Gate Valve Class 300
Design StandardANSI / DIN
PressurePN1
Sizes150x150 to 1000x1000
Sectors- Other - Pulp and Paper
MaterialsBody        : Carbon Steel / AISI304 / AISI316 Knife        :AISI304 / AISI316 Packing : Synth+PTFE, Graphite, o-ring
SeatEPDM, Metal/Metal, Silicone, Viton
Operation typeBevel Gear, Electric Actuator, Handwheel, Hydraulic Actuator, Lever, Pneumatic
ApplicationsCharged fluids, Discharge bins, Tanks
Accessories & OptionsDeflector cone, Emergency System, Emergency closing devices, Filters, Injection holes, Junction box, Limit Switches, Proximity switches, Reinforced socket, Scraper, Solenoid valves, Stem extension

FCA Bi-Directional Design

The GM Model FCA Slurry Knife Gate Valve

The FCA GM model knife gate valve is the long pattern face to face FCA slurry knife gate design. Its double-seated design offers a bidirectional shut-off. These seats or rubber sleeves are provided with an internal metal core.

Features
  • Reinforced sleeves
  • Not stem packing required
Accesories & Option
  • Flushing plate
  • Retaining flanges
FCA Rating
  • FCA Slurry Knife Gate Valve Class 150
  • FCA Slurry Knife Gate Valve Class 300
Design StandardANSI / DIN
PressureUp to 10bar.
SizesDN50/2'' to DN1200/48''
Sectors- Minerals - Other - Pulp and Paper - Steel Industry
MaterialsBody  : Carbon Steel Knife  : AISI304 / AISI316 Seal    :NBR
SeatAbrasion-resistant Natural Rubber (NR) Sleeves
Operation typeBevel Gear, Electric Actuator, Handwheel, Hydraulic Actuator, Lever, Pneumatic Actuator
ApplicationsAbrasive media, Mining, Sludge, Slurry
Accessories & OptionsEmergency System, Emergency closing devices, Filters, Flushing plate, Injection holes, Junction box, Limit Switches, Locking devices, Proximity switches, Solenoid valves, Stem extension

FCA
SLURRY KNIFE GATE VALVE

FCA Bi-Directional Design

The GM Model FCA Slurry Knife Gate Valve

The FCA GM model knife gate valve is the long pattern face to face FCA slurry knife gate design. Its double-seated design offers a bidirectional shut-off. These seats or rubber sleeves are provided with an internal metal core.

Features
  • Reinforced sleeves
  • Not stem packing required
Accesories & Option
  • Flushing plate
  • Retaining flanges
FCA Rating
  • FCA Slurry Knife Gate Valve Class 150
  • FCA Slurry Knife Gate Valve Class 300
Design StandardANSI / DIN
PressureUp to 10bar.
SizesDN50/2'' to DN1200/48''
Sectors- Minerals - Other - Pulp and Paper - Steel Industry
MaterialsBody  : Carbon Steel Knife  : AISI304 / AISI316 Seal    :NBR
SeatAbrasion-resistant Natural Rubber (NR) Sleeves
Operation typeBevel Gear, Electric Actuator, Handwheel, Hydraulic Actuator, Lever, Pneumatic Actuator
ApplicationsAbrasive media, Mining, Sludge, Slurry
Accessories & OptionsEmergency System, Emergency closing devices, Filters, Flushing plate, Injection holes, Junction box, Limit Switches, Locking devices, Proximity switches, Solenoid valves, Stem extension

FCA
SLURRY KNIFE GATE VALVE

FCA
TAPPI KNIFE GATE VALVE

FCA Comply With ISO 9001-2015 Quality Standard

The GTAPPI Model FCA Tappi Knife Gate Valve

The GTAPPI model FCA standard knife gate valve is a full bore execution with cast monoblock body. It can be installed between flanges or at the end of the line.

Features
  • Reinforced seat ring
  • Single monoblock robust body
Accesories & Option
  • Protection covers
  • Emergency closing device
FCA Rating
  • FCA Tappi Knife Gate Valve Class 150
  • FCA Tappi Knife Gate Valve Class 300
Design StandardANSI / DIN
PressurePN10
SizesDN50/2'' to DN600/24''
Sectors- Hydro Power Plants and Dams - Mineral - Oil and Gas - Power - Pulp and Paper - Steel Industry - Thermal Power Plants - Water
MaterialsBody        : GG25 / A351CF8M Knife        : AISI304 / AISI316 Packing : Synth+PTFE, Graphite, o-ring
SeatEPDM, Metal/Metal, Nitrile, PTFE, Silicone, Viton
Operation typeBevel Gear, Electric Actuator, Handwheel, Hydraulic Actuator, Lever, Pneumatic Actuator
ApplicationsCharged fluids, Paper pulp, Sludge, Solids
Accessories & OptionsDeflector cone, Emergency System, Emergency closing devices, Filters, Injection holes, Junction box, Limit Switches, Proximity switches, Reinforced socket, Solenoid valves, Stem extension, V or pentagonal port

FCA Bolted Bonnet Gate Valve

The SB Model FCA General Service Gate Valve

The SB type FCA Gate model is full bore with cast body and flexible wedge. The sealing is metal-metal with Stellite 6 overlay to ensure sufficient hardness and tight sealing. External leaks are ensured with the bonnet.

Features
  • Metal seated
  • Forged T-Stem design
  • Bellows stem sealing on request
FCA Rating
  • FCA Gate Valve Class 150
  • FCA Gate Valve Class 300
  • FCA Gate Valve Class 600
  • FCA Gate Valve Class 900
  • FCA Gate Valve Class 1500
Design StandardAPI / ASME
SizesDN50/2'' to DN1500/60''
Sectors- Mineral - Oil and Gas - Petrochemical Plants - Power - Steel Industry - Thermal Power Plants - Water
MaterialBody : WCB / WCC / A105 / LCB / LCC / LF2/ WC6 / CF8M / CF3M / F316 / F51 / F44... Gate  : WCB / WCC / A105 / LCB / LCC / LF2/ WC6 / CF8M / CF3M / F316 / F51 / F44 ...
SeatA182 F316, A182 F51, A182 F6
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsCorrosive fluids, Natual Gas Pipelines, Oil Pipelines, Refineries, Water pump stations
Accessories & OptionsEmergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA
GENERAL SERVICE VALVE

FCA Bolted Bonnet Gate Valve

The SB Model FCA General Service Gate Valve

The SB type FCA Gate model is full bore with cast body and flexible wedge. The sealing is metal-metal with Stellite 6 overlay to ensure sufficient hardness and tight sealing. External leaks are ensured with the bonnet.

Features
  • Metal seated
  • Forged T-Stem design
  • Bellows stem sealing on request
FCA Rating
  • FCA Gate Valve Class 150
  • FCA Gate Valve Class 300
  • FCA Gate Valve Class 600
  • FCA Gate Valve Class 900
  • FCA Gate Valve Class 1500
Design StandardAPI / ASME
SizesDN50/2'' to DN1500/60''
Sectors- Mineral - Oil and Gas - Petrochemical Plants - Power - Steel Industry - Thermal Power Plants - Water
MaterialBody : WCB / WCC / A105 / LCB / LCC / LF2/ WC6 / CF8M / CF3M / F316 / F51 / F44... Gate  : WCB / WCC / A105 / LCB / LCC / LF2/ WC6 / CF8M / CF3M / F316 / F51 / F44 ...
SeatA182 F316, A182 F51, A182 F6
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsCorrosive fluids, Natual Gas Pipelines, Oil Pipelines, Refineries, Water pump stations
Accessories & OptionsEmergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA
GENERAL SERVICE VALVE

FCA
PRESSURE SEAL GATE VALVE

FCA Pressure Seal Bonnet Design Gate Valve

The SP Model FCA Pressure Seal Gate Valve

The SP type FCA Pressure Seal gate model is full bore with cast body. The sealing is metal-metal with Stellite 6 overlay to ensure sufficient hardness and tight sealing.

Features
  • Forged T-Stem design
  • Suitable for pigging operations
  • Bellow stem sealing on request
  • OS&Y risign stem configuration
FCA Rating
  • FCA Pressure Seal Gate Valve Class 600
  • FCA Pressure Seal Gate Valve Class 900
  • FCA Pressure Seal Gate Valve Class 1500
  • FCA Pressure Seal Gate Valve Class 2500
Design StandardAPI / BS
SizesDN80/3'' to DN900/36''
Sectors- Oil and Gas - Pterocheimcal Plants - Power - Thermal Power Plants
Material
Body     : A217 WC6 / A217 WC9... Wedge : A217 WC6 / A217 WC9...
Operation typeElectric Actuator, Gearbox, Hydraulic Actuator, Manual, Pneumatic Actuator
ApplicationsCorrosive fluids, Fertilizer Plants, High Temperature, Natual Gas Pipelines, Oil Pipelines, Refineries, Steam Isolation
Accessories & OptionsBy-pass, Emergency System, Filters, Junction box, Limit Switches, Proximity switches, Solenoid valve, Stem extension

FCA Nozzle Type Non Slam Disc Check Valve

The RN Model FCA Nozzle Type Check Valve

The RN type FCA Nozzle Check prevents reverse flow by a slowly sealing before the pump stops. Its short pattern design reduces the closing time avoiding water hammer.

FCA Features
  • Easy maintenance
  • API 6D compliance design
  • Short stroke for quick response valve
  • Carbon steel or stainless steel
FCA Accesories & Option
  • Soft and metal seated design
  • Superior size
  • Superior pressure
  • Different face to face on request
Design StandardAPI / ASME
SizesDN50/2'' to DN600/24''
Sectors- Hydro Power Plants and Dams - Mineral - Oil and Gas - Petrochemical Plants - Power - Steel Industry - Thermal Power Plants - Water
MaterialBody : A216 WCB / A351 CF8M / A890 Gr4A... Disc   :A216 WCB / A351 CF8M / A890 Gr4A...
SeatA182 F316, A182 F51, A182 F6, Viton
ApplicationsCorrosive fluids, Natual Gas Pipelines, Oil Pipelines, Refineries, Water pump stations

FCA
NOZZLE TYPE CHECK VALVE

FCA Nozzle Type Non Slam Disc Check Valve

The RN Model FCA Nozzle Type Check Valve

The RN type FCA Nozzle Check prevents reverse flow by a slowly sealing before the pump stops. Its short pattern design reduces the closing time avoiding water hammer.

FCA Features
  • Easy maintenance
  • API 6D compliance design
  • Short stroke for quick response valve
  • Carbon steel or stainless steel
FCA Accesories & Option
  • Soft and metal seated design
  • Superior size
  • Superior pressure
  • Different face to face on request
Design StandardAPI / ASME
SizesDN50/2'' to DN600/24''
Sectors- Hydro Power Plants and Dams - Mineral - Oil and Gas - Petrochemical Plants - Power - Steel Industry - Thermal Power Plants - Water
MaterialBody : A216 WCB / A351 CF8M / A890 Gr4A... Disc   :A216 WCB / A351 CF8M / A890 Gr4A...
SeatA182 F316, A182 F51, A182 F6, Viton
ApplicationsCorrosive fluids, Natual Gas Pipelines, Oil Pipelines, Refineries, Water pump stations

FCA
NOZZLE TYPE CHECK VALVE

FCA
PRESSURE SEAL CHECK VALVE

FCA Pressure Seal Swing Type Check Valve

The RPS Model FCA Pressure Seal Check Valve

The RPS model FCA pressure seal swing type check valve is a metal seated non-return valve with a single disc mounted on an arm that rotated on a hinge pin. It is a unidirectioal design that only allows fluid circulating in one direction, preventing backflow.

Features
  • Lifting points
  • Uni-directional flow
FCA Rating
  • FCA Pressure Seal Check Valve Class 600
  • FCA Pressure Seal Check Valve Class 900
  • FCA Pressure Seal Check Valve Class 1500
  • FCA Pressure Seal Check Valve Class 2500
Design StandardAPI / ASME
SizesDN50/2'' to DN600/24''
Sectors- Mineral - Oil and Gas - Petrochemical Plants - Power - Steel Industry - Thermal Power Plants
MaterialBody : A217 WC6 / A217 WC9... Disc   : A217 WC6 / A217 WC9...
SeatA182 F11, A182 F12, A182 F6
ApplicationsCorrosive fluids, Fertilizer Plants, High Temperature, Natual Gas Pipelines, Oil Pipelines, Refineries, Steam Isolation

FCA Bolted Bonnet Design Swing Check Valve

The RS Model FCA Swing Type Check Valve

The RS type FCA Swing check is a metal seated non-return valve with a single disc mounted on an arm that rotated on a hinge pin. It is a unidirectioal design that only allows fluid circulating in one direction, preventing backflow and it has flanged connections

Applications
  • Natural gas pipelines
  • Oil pipelines
  • Refineries
FCA Rating
  • FCA Swing Check Valve Class 150
  • FCA Swing Check Valve Class 300
  • FCA Swing check Valve Class 600
Design StandardAPI / ASME
SizesDN50/2'' to DN600/24''
Sectors- Mineral - Oil and Gas - Petrochemical Plants - Power - Steel Industry - Thermal Power Plants - Water
MaterialBody : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A... Disc   : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A...
SeatMetal/Metal
ApplicationsCorrosive fluids, Natual Gas Pipelines, Oil Pipelines, Refineries, Water pump stations

FCA
SWING TYPE CHECK VALVE

FCA Bolted Bonnet Design Swing Check Valve

The RS Model FCA Swing Type Check Valve

The RS type FCA Swing check is a metal seated non-return valve with a single disc mounted on an arm that rotated on a hinge pin. It is a unidirectioal design that only allows fluid circulating in one direction, preventing backflow and it has flanged connections

Applications
  • Natural gas pipelines
  • Oil pipelines
  • Refineries
FCA Rating
  • FCA Swing Check Valve Class 150
  • FCA Swing Check Valve Class 300
  • FCA Swing check Valve Class 600
Design StandardAPI / ASME
SizesDN50/2'' to DN600/24''
Sectors- Mineral - Oil and Gas - Petrochemical Plants - Power - Steel Industry - Thermal Power Plants - Water
MaterialBody : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A... Disc   : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A...
SeatMetal/Metal
ApplicationsCorrosive fluids, Natual Gas Pipelines, Oil Pipelines, Refineries, Water pump stations

FCA
SWING TYPE CHECK VALVE

FCA
TILTING DISC CHECK VALVE

FCA Tilting Disc and Dual Plate

The RT Model FCA Tilting Disc Check Valve

The RT model FCA tilting disc check is a metal seated non-return valve, with a single disc and casted monoblock body.

FCA Applications
  • Water
  • Steam
  • Pulp & Paper
  • Food
  • Oil & gas
FCA Sectors
  • Paper industry
  • Cement industry
  • Chemical & petrochemical plants
  • Mining & siderurgy
  • Water treatment plants
Design StandardDIN
PressurePN10 / PN16 / PN25 / PN40
SizesDN50/2'' to DN600/24''
Sectors- Mineral - Pulp and Paper - Steel Industry - Water
MaterialBody : ASTM A216 WCB / ASTM A351 CF8M... Disc   : ASTM A216 WCB / ASTM A351 CF8M / ASTM 890 Gr4A...
SeatMetal/Metal
ApplicationsDrinking Water, Waste Water

FCA Damper

Flap Valve

The DFL model FCA flap type damper is designed for pneumatic transport applications and is used to isolate air or industrial gas in combustion and various process lines where temperatures may reach up to 900ºC.
